Our company has an entire international Tin bath refractory brick for glass furnace, Quartz firebrick for glass furnace top, High rapid cooling and heating refractory brick production line. Over the years, we have won the recognition of our customers and friends from all walks of life with good professionalism, superb technology and enthusiastic and efficient service. We welcome you to come and inspect! By following the spirit of 'good faith, customers come first, quality first, keep improving', our company continuously keeps forging ahead, innovative and expanding to strive for the top.
1,Description of Insulating Silica Brick:
Using finely silica raw materials.Use at high temperatures, can not contact with alkaline refractory materials. With heat conduction performance is good, Refractoriness, small residual expansion,Strong acid slag erosion resistance, etc.Light weight silica brick is mainly used in two fields. One is the heat insulation on the top of glass kiln to reduce heat loss and increase the efficiency of melting process.The other is the heat insulation of the wall and top of the hot blast stove. The vault of glass furnace is usually designed with two layers of thermal insulation, and the density of brick is 1.0g/cm3 and 0.8g/cm3 or 0.6g/cm3 respectively.The density of lightweight silica brick for hot blast stove is usually 1.05g/cm3 and 1.25g/cm3.Lightweight silica brick, also known as lightweight insulation brick, contains more than 91% silica and has a density of less than 1.2g/cm3. The particle size of production burden is not more than 1 mm. Flammable substances are added in the burden to form porous structure in the firing process. The use temperature is above 1200 ℃ and cannot contact with alkaline refractory.
2,Index of Insulating Silica Brick:
| Item | JS-1.00 | JS-1.20 |
Chemical analysis SiO2 % | ≥91 | ≥91 |
Bulk density g/cm3 | ≤1.00 | ≤1.20 |
Cold crushing strength Mpa | ≥2.0 | ≥5.0 |
Refactoriness Under Load 0.2MPa℃ | ≥1400 | ≥1520 |
Reheating Linear Change % | 1450℃*2h ≤0.5 | 1550℃*2h |
Thermal conductivity W/M·K (350℃±10) | ≤0.55 | ≤0.70 |
3,Knowledge of Insulating Silica Brick:
Insulating Silica Brick uses fine silica as raw material, the maximum particle size is 1mm, of which the particle size less than 0.5mm is more than 90%.The porous structure is formed by adding flammable substances into the ingredients or by gas generation method,It is made by firing.Insulating Silica Brick can not be used in contact with alkaline refractories at high temperature. According to the material, the maximum temperature is 1200 ~ 1500℃.In addition to thermal insulation, the product also maintains the characteristics of silicon brick, high refractoriness under load, slightly expanding volume in the heating process, so as to enhance the overall performance of the kiln.
4,Product shape and classification:
Most of the products are standard bricks, size 230*114*65mm, according to density, can be divided into:JS-1.00,JS-1.10,JS-1.15,JS-1.20
5,Product packaging, storage:
wooden pallet + stretch film + fastening plastic steel strip, storage in moisture-proof and ventilated environment, storage time of more than 12 months.
6.Good feedback of product use effect,the products have been exported to South Korea, Japan, Pakistan
7.We are a professional supplier, who can provide customers with free product technology, use and other issues.
Do you want to find a professional supplier of refractory products?
Do you want to find a stable and credible supplier?
Then please contact with us
Contact me:Email:wp@cnjingganrefractory.com/sdwenping@163.com
TEL: 86-0533-4188518 / FAX: 86-0533-4188518
Rose:+86-13275332819(wechat/whatsapp number)
And we will provide the best quality Refractory High Temperature Magnesia-Chrome Brick to serve our customers according to the needs of customers in the shortest time. We uphold the business philosophy of 'creating value for customers', and have won the trust and support of many customers with reasonable prices, excellent quality, and perfect services. Our serious and responsible attitude guides our way of doing business and we meet the growing demands of consumers in a resource-limited market.
